- Portable, Indigenously Designed
- Microprocessor Controlled constant current
- Reliable & Accurate
All in one unit for...
- Neuromusular Monitoring
- Transcutaneous Mapping of the Peripheral Nerves
- Nerve Location
Nerve Mapper Mode (For Transcutaneous Tracing):
It helps to indentify the entry point thereby reducing patient discomfort. also useful in defining anatomical landmarks, especially in growing children, obese patients and in case of patients with distored anatomy.
Nerve Locator Mode (Monitor):
Excellent for reliable location of nerves using very low current, thereby increasing the success rate of regional Anesthesia and reducing risk of nerve damage as compared to paresthesia technique, also useful in...
Identifying/Locating Motor and Mixed Nerve
- Identifying Nerve during Neuro, Ortho, Ent, Pacdiatric and Plastic Surgey. (eg. Facial Nerve).
- Pain Clinic
Nerve Locator Mode (Sensory):
A unique model to identify sensory nerves like lossopharyngeal and other nerves in pain management.
Accessories:
- Transcutaneous Mapping Probe with Cable
- Interface Cable Pairs for Locator and Stimulatior
- Mains Adaptor
- Rechargeable Battery
- Separate output for Nerve Stimulator - Mapper and Locator for safety.
- Automatic switch over from mains power adaptor to rechargeable 9Vbattery with low battery warning indicator.
- Feather-touch keypad for easy operation, simple setting and extended reliability.
- Variable current range as per the selected mode(impedane:0 to 5 kohm).
- User programmable pulse width and frequency.
- Alphanumeric LCD display with back light.
- Automatic shutdown for power saving.
- Audio and back light on-off option.
- Small, Light-weight and user friendly.
- Compact size 100mm X 180mm X 40mm.
- Weight 425gm without battery.
Wide range for Stimulation Modes
- Twitch: On Demand/Repeat at 1 Sec/Repeat at 10 Sec
- Train of Four(Tof): On Demand/Repeat at 10 Sec
- Tetanus(50Hz)
- Double Burst Stimulation (dbs)(3.3)
- Post Tetanic Count (ptc)
- User Programmable for Continuous Monitoring (1 to 30 Min)
- Auto Setting for Super maximal Current
- Audible Alert before actual pulse delivery
